Start here
Analog Devices AN-562 Application Note
This document provides detailed filter specifications and frequency response plots for the internal filters of the ADV7190, ADV7191, ADV7192, and ADV7194 video encoders. It covers various filter types including luma low-pass, luma notch, extended SSAF, and chroma filters.
Read onlineAnalog Devices ADV7194 specifications
| Resolution (Each DAC) | 10 Bits |
|---|---|
| Input High Voltage | 2 V |
| Output High Voltage | 2.4 V |
| PLL Output Frequency | 54 MHz |
All Analog Devices ADV7194 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
How to use the product for one specific task, with worked examples.
Questions answered in these manuals
What video encoder models does this application note cover?
This document provides filter specifications for the ADV7190, ADV7191, ADV7192, and ADV7194 video encoders.
What is the range of programmable gain and attenuation for the SSAF filter?
The SSAF filter offers programmable gain and attenuation responses in the range of -4 dB to +4 dB.
What video standards does the ADV7194 support?
It supports NTSC‑M, NTSC‑N (Japan), PAL‑N, PAL‑B/D/G/H/I and PAL‑60 standards.
What supply voltages can be used with the ADV7194?
The device can operate from either a 5 V or a 3.3 V supply.
What video standards does the ADV7194 support?
It supports NTSC‑M, NTSC‑N (Japan), PAL‑N, PAL‑B/D/G/H/I and PAL‑60 standards.
What is the oversampling factor of the ADV7194?
The device uses 4× oversampling with an internal 54 MHz PLL.
