Start here
ANALOG DEVICES AD96685/AD96687: Ultra Fast ECL Comparator Data Sheet (Rev D 2002-02-01-) handbook
The AD96685 and AD96687 are ultrafast voltage comparators designed for high-speed applications such as triggers, line receivers, and threshold detection. The AD96685 is a single comparator with a 2.5 ns propagation delay, while the AD96687 is a dual comparator with identical performance. Both devices feature a 50 ps propagation delay dispersion and operate with ECL logic compatibility.
Read onlineAnalog Devices AD9668 specifications
| Propagation Delay | 2.5 ns |
|---|---|
| Propagation Delay Dispersion | 50 ps |
| Power Supply | +5 V, –5.2 V |
| Logic Compatibility | ECL 10 K and 10 KH |
| Output Type | Open Emitter |
Source: ANALOG DEVICES AD96685/AD96687: Ultra Fast ECL Comparator Data Sheet (Rev D 2002-02-01-) handbook
All Analog Devices AD9668 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the propagation delay of the AD96685?
The AD96685 has a propagation delay of 2.5 ns.
From: ANALOG DEVICES AD96685/AD96687: Ultra Fast ECL Comparator Data Sheet (Rev D 2002-02-01-) handbook
How many comparators does the AD96687 contain?
The AD96687 is a dual comparator.
From: ANALOG DEVICES AD96685/AD96687: Ultra Fast ECL Comparator Data Sheet (Rev D 2002-02-01-) handbook
What are the applications of the AD9668?
It is used in DVD-R, DVD+R, DVD-RW, DVD+RW, DVD-RAM supercombo drives, MO drives, and for laser diode current switching.
From: Analog Devices AD9668 4-Channel LVDS Laser Diode Driver Datasheet
How is the output current level set?
The level of the output current is set by an external resistor that converts an input voltage into a current at the xSET pins.
From: Analog Devices AD9668 4-Channel LVDS Laser Diode Driver Datasheet
What supply voltages are required for the comparators?
They require a +5 V positive supply and a –5.2 V negative supply.
What temperature range can the devices operate in?
Both devices are rated for an industrial temperature range of –25 °C to +85 °C.
