Analog Devices ADXL330 3-Axis Accelerometer Datasheet
The document is a technical specification sheet for the ADXL330, a monolithic IC designed as a complete three-axis accelerometer. It features a minimum full-scale range of ±3 g and includes signal-conditioned voltage outputs on a single chip.
Key characteristics include low power consumption (200 μA typical at 2.0 V), excellent shock survival up to 10,000 g, and adjustable bandwidth per axis using external capacitors. The device operates with a single supply voltage ranging from 2.0 V to 3.6 V.
Analog Devices ADXL330 specifications
| Measurement Range | ±3 g (Min), ±3.6 g (Max) |
|---|---|
| Supply Voltage | 2.0 V to 3.6 V |
| Supply Current (Typical) | 200 μA at 2.0 V |
| Operating Temperature Range | -25°C to +70°C |
| Package Dimensions | 4 mm × 4 mm × 1.45 mm |
Source: Analog Devices ADXL330 3-Axis Accelerometer Datasheet
All Analog Devices ADXL330 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the bandwidth range for the X and Y axes?
The bandwidth ranges from 0.5 Hz to 1,600 Hz for the X and Y axes.
How is the bandwidth adjusted?
The user selects the bandwidth using capacitors (CX, CY, CZ) at the respective output pins.
What is the measurement range of the ADXL330?
The ADXL330 measures acceleration over a full‑scale range of ±3 g.
What supply voltage does the ADXL330 require?
It operates from a single supply voltage between 2.0 V and 3.6 V.
