Key facts
- Brand
- Analog Devices
- Model
- AD532
- Category
- Other Electronics
- Documents
- 12
- Languages
- EN
- Last added
- 2012-08-02
Start here
Analog Devices AD5308/AD5318/AD5328 Octal DAC Datasheet
The AD5308/AD5318/AD5328 are octal 8-, 10-, and 12-bit buffered voltage output DACs in a 16-lead TSSOP package. They operate from a single 2.5 V to 5.5 V supply, consuming 0.7 mA typical at 3 V. Their on-chip output amplifiers allow the outputs to swing rail-to-rail with a slew rate of 0.7 V/μs.
Read onlineAnalog Devices AD532 specifications
| Supply Voltage | 2.5 V to 5.5 V |
|---|---|
| Package | 16-lead TSSOP |
| Power-Down Current | 120 nA @ 3 V |
| Slew Rate | 0.7 V/μs |
| Temperature Range | -40°C to +125°C |
Source: Analog Devices AD5308/AD5318/AD5328 Octal DAC Datasheet
All Analog Devices AD532 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
- Analog Devices AD5308/AD5318/AD5328 Octal DAC Datasheet 28 p
- Analog Devices AD5304/AD5314/AD5324 Datasheet 24 p
- Analog Devices AD5324-EP Quad 12-Bit DAC Datasheet 12 p
- Analog Devices AD5305/AD5315/AD5325 Quad Voltage Output DAC Datasheet 20 p
- ANALOG DEVICES 2.5 V to 5.5 V 400 A Quad Voltage Output 8-/10-/12-Bit DACs in 16-Lead TSSOP AD5307/AD5317/AD5327 handbook 28 p
- Analog Devices AD5320 12‑Bit DAC Datasheet Rev C 20 p
- Analog Devices AD5302/AD5312/AD5322 Dual‑Channel DAC Datasheet 24 p
- Analog Devices AD5306/AD5316/AD5326 Product Handbook 24 p
- Analog Devices AD5303/AD5313/AD5323 Datasheet 18 p
- ANALOG DEVICES +2.5 V to +5.5 V 230 mA Dual Rail-to-Rail Voltage Output 8-/10-/12-Bit DACs AD5302/AD5312/AD5322* handbook 16 p
- Analog Devices AD5301/AD5311/AD5321 Datasheet 16 p
- Analog Devices AD532 Datasheet 8 p
Questions answered in these manuals
What is the typical current consumption at 3V?
The typical current consumption is 0.7 mA at 3 V.
From: Analog Devices AD5308/AD5318/AD5328 Octal DAC Datasheet
Can the outputs be updated simultaneously?
Yes, the outputs of all DACs may be updated simultaneously using the asynchronous LDAC input.
From: Analog Devices AD5308/AD5318/AD5328 Octal DAC Datasheet
What is the output voltage range?
The output range is 0 V to Vref.
Is the device guaranteed monotonic?
Yes, it is guaranteed monotonic by design over all codes.
What is the temperature range for the AD5324-EP?
The device supports a military temperature range from -55°C to +125°C.
What is the resolution of the AD5324-EP?
The AD5324-EP provides a resolution of 12 bits.
