Start here
Analog Devices AD9265/AD9255 Evaluation Board User Guide UG-074
The document provides a comprehensive overview of the AD9265/AD9255 Evaluation Board (UG-074), detailing the required equipment, necessary software, and general description of the board's purpose. It explains how to connect the evaluation board with data capture kits and signal sources for characterizing Analog-to-Digital Converters.
Read onlineAnalog Devices AD9265 specifications
| Resolution | 16 Bits |
|---|---|
| Sample Rate (Max) | 125 MSPS |
| Input Bandwidth | 650 MHz |
All Analog Devices AD9265 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the resolution of the AD9265?
The device provides a full 16-bit resolution.
What output formats are supported?
The converter supports parallel 1.8 V CMOS or LVDS (DDR) outputs.
What software is needed to interface with the devices?
The VisualAnalog SPI controller and SPI control software are required.
From: Analog Devices AD9265/AD9255 Evaluation Board User Guide UG-074
Can the evaluation board be powered by external bench power supplies?
Yes, by removing specific jumpers (P27, P28, P31, P30, P32, and P29) to disconnect the on-board LDOs.
From: Analog Devices AD9265/AD9255 Evaluation Board User Guide UG-074
How is the AD9265 configured?
Configuration is performed via a 3‑wire SPI‑compatible serial port interface.
