Start here
Analog Devices AD9467 Evaluation Board User Guide UG-200
The document provides a comprehensive user guide for the Analog Devices AD9467 Evaluation Board (UG-200). It details the features of the full-featured board designed to evaluate the 16-bit, 200 MSPS/250 MSPS ADC. The guide covers necessary equipment, required documents and software, and a typical measurement setup involving an analog signal source and data capture boards.
Read onlineAnalog Devices AD9467 specifications
| Resolution | 16-Bit |
|---|---|
| Sampling Rate | 200 MSPS/250 MSPS |
| Reference Voltage (Default) | 1.25 V |
| Full-Scale Range | 2.0 V p-p to 2.5 V p-p |
| Power Supply Current | 2.5 A maximum output |
Source: Analog Devices AD9467 Evaluation Board User Guide UG-200
All Analog Devices AD9467 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
How to use the product for one specific task, with worked examples.
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What software is needed to interface with the AD9467?
The VisualAnalog and SPI Controller software interfaces are used.
From: Analog Devices AD9467 Evaluation Board User Guide UG-200
Is an external reference option available on the board?
Yes, a separate external reference option using the ADR130 is included.
From: Analog Devices AD9467 Evaluation Board User Guide UG-200
What is the total insertion loss of the filter network and other components?
The total insertion loss due to the filter network and other components is only 1.8 dB.
From: Analog Devices CN-0227 Circuit Note for AD9467/ADL5562 Receiver Front End
What is the bandwidth of the overall circuit?
The overall circuit has a bandwidth of 152 MHz.
From: Analog Devices CN-0227 Circuit Note for AD9467/ADL5562 Receiver Front End
What is the maximum sampling rate of the AD9467?
The AD9467 can sample at up to 250 MSPS.
From: Analog Devices AD9467 16‑Bit 200/250 MSPS ADC Data Sheet
What supply voltages are required for the AD9467?
It requires AVDD1 = 1.8 V, AVDD2 = 3.3 V, AVDD3 = 1.8 V for analog sections and DRVDD = 1.8 V for digital output drivers.
From: Analog Devices AD9467 16‑Bit 200/250 MSPS ADC Data Sheet
