Start here
ANALOG DEVICES UG-327 handbook
This document is the User Guide (UG-327) for the EVAL-AD5443/AD5446/AD5453SDZ evaluation board. It supports the AD5443, AD5446, and AD5453 current output/serial input DACs and includes instructions for using the accompanying graphic user interface software for board control and data analysis.
The guide details the installation and operation of the LabVIEW software and drivers required to communicate with the board via the EVAL-SDP-CB1Z system demonstration platform. It provides specific examples for configuring the AD5443, AD5446, and AD5453 parts, including data writing, readback verification, and daisy-chain mode settings. Additionally, the document contains schematics and artwork for the evaluation board.
Analog Devices AD5446 specifications
| DAC Resolution | 12-bit, 14-bit |
|---|---|
| Power Supply (AD5443) | 3 V to 5.5 V |
| Power Supply (AD5446/AD5453) | 2.5 V to 5.5 V |
| Interface | 3-wire serial |
| Compatible Standards | SPI, QSPI, MICROWIRE |
| Package (AD5443/AD5446) | 10-lead MSOP |
| Package (AD5453) | 8-lead TSOT, MSOP, LFCSP |
Source: ANALOG DEVICES UG-327 handbook
All Analog Devices AD5446 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What software is included with the evaluation board?
The evaluation kit includes the software and drivers on CD, specifically the LabVIEW software and the SDPDriversNET driver.
How do I connect the evaluation board to the PC?
Connect the evaluation board to the SDP board and then plug the SDP board into the PC using the USB cable included in the box.
What is the maximum serial clock frequency for these DACs?
The maximum clock frequency is 50 MHz.
What reference voltage can be applied to the AD5444/AD5446?
A reference input up to +10 V is supported.
