Key facts
- Brand
- Analog Devices
- Model
- AD9284
- Category
- Other Electronics
- Documents
- 2
- Languages
- EN
- Last added
- 2012-08-02
Start here
ANALOG DEVICES UG-178 handbook
This document is the user guide for the AD9284 evaluation board, which provides all necessary support circuitry to operate the AD9284 analog-to-digital converter in various modes. It details the equipment and software needed, including VisualAnalog and SPIController interfaces.
Read onlineAnalog Devices AD9284 specifications
| Power Supply Output | 6 V, 2 A maximum |
|---|---|
| Input Frequency Range | up to ~200 MHz |
| Reference Voltage | 1.0 V |
| RBIAS Default Setting | 10 kΩ |
Source: ANALOG DEVICES UG-178 handbook
All Analog Devices AD9284 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What software is needed to interface with the AD9284 evaluation board?
The required software includes VisualAnalog and SPIController.
How do I enable the power-down feature on the board?
Add a shorting jumper across J202 at Pin 2 and Pin 3 to connect the SDIO/PDWN pin to DRVDD.
What supply voltage does the AD9284 require?
The AD9284 operates from a single 1.8 V supply for both analog (AVDD) and digital output (DRVDD) domains.
From: Analog Devices AD9284 8‑Bit 250 MSPS Dual ADC Datasheet
How many bits of resolution does the AD9284 provide?
It provides 8‑bit resolution.
From: Analog Devices AD9284 8‑Bit 250 MSPS Dual ADC Datasheet
