Key facts
- Brand
- Analog Devices
- Model
- AD5060
- Category
- Other Electronics
- Documents
- 3
- Languages
- EN
- Last added
- 2012-08-02
Start here
Analog Devices 8-Bit to 16-Bit nanoDAC Converters Product Leaflet
This document introduces the Analog Devices nanoDAC converter family, which offers the highest performance in the industry's smallest packaging. The family includes 8-bit to 16-bit Digital-to-Analog Converters (DACs) designed for consumer and industrial applications, ensuring best possible performance, smallest package size, and greater overall value.
Read onlineAnalog Devices AD5060 specifications
| Resolution (AD5641) | 14 Bits |
|---|---|
| Resolution (AD5621) | 12 Bits |
| Resolution (AD5660) | 16 Bits |
| Resolution (AD5060) | 16 Bits |
| Power supply range | 2.7V to 5.5 V |
| Linearity (AD5660) | 16 LSB INL |
| Linearity (AD5060) | 1 LSB INL |
| Reference accuracy | 10 ppm/°C |
Source: Analog Devices 8-Bit to 16-Bit nanoDAC Converters Product Leaflet
All Analog Devices AD5060 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the main advantage of the nanoDAC family?
They are the smallest DACs in the world but are also more accurate and lower power than the competition.
From: Analog Devices 8-Bit to 16-Bit nanoDAC Converters Product Leaflet
What is the linearity of the AD5660?
The AD5660 has a linearity of 16 LSB INL.
From: Analog Devices 8-Bit to 16-Bit nanoDAC Converters Product Leaflet
What is the supply voltage range for the AD5040?
The AD5040 can be operated from 2.7V to 5.5V.
What is the supply voltage range for the AD5060?
The AD5060 can be operated at 3V or 5V.
