Start here
Analog Devices AD5064 Evaluation Board User Guide UG-144
This document is a user guide for the Analog Devices AD5064 Evaluation Board. It details the hardware features, including power supply options and link settings for PC control via USB or external SMB connectors. The board supports a single 4.5 V to 5.5 V supply and includes an on-board reference (REF195) and ADC for voltage readback. This manual is written in Chinese.
Read onlineAnalog Devices AD5064 specifications
| Resolution | 16 bits (AD5064/AD5064‑1) |
|---|---|
| Supply Voltage Range | 4.5 V to 5.5 V |
| Maximum Serial Clock Frequency | 50 MHz |
| Power‑Down Current Consumption | ≈ 400 nA at 5 V |
| Operating Temperature Range | ‑40 °C to +125 °C |
Source: Analog Devices AD5024/AD5044/AD5064 Product Handbook
All Analog Devices AD5064 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the default link setup for control?
The default setup is for control by the PC via the USB port.
From: Analog Devices AD5064 Evaluation Board User Guide UG-144
Does the board include an on-board reference voltage?
Yes, there is an external reference which is the REF195 on this evaluation board.
From: Analog Devices AD5064 Evaluation Board User Guide UG-144
What supply voltage range does the AD5024/AD5044/AD5064 require?
The devices operate from a single 4.5 V to 5.5 V supply.
What is the maximum serial clock frequency for the SPI interface?
The serial clock can run up to 50 MHz.
What supply voltage range does the AD5064 support?
The AD5064 operates from a 4.5 V to 5.5 V supply.
What is the maximum serial clock frequency for the device?
The serial clock can run up to 50 MHz.
