Analog Devices UG-324 Evaluation Board User Guide
This document is the user guide for the AD5116 Digital Potentiometer Evaluation Board (EV-AD5116EBZ). It provides an overview of the board's features, including its support for single-supply operation from 2.3 V to 5.5 V and its ability to store the last wiper position in EEPROM. The guide outlines the package contents and general description of the hardware.
Read onlineAnalog Devices AD5116 specifications
| Supply Voltage Range | 2.3 V to 5.5 V |
|---|---|
| Current Density | ±6 mA |
| Resistor Tolerance | ±8% |
| Part Number | EV-AD5116EBZ |
All Analog Devices AD5116 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the purpose of the NVM push button?
It allows manual storage of the RDAC register into the NVM when the ASE function is disabled.
How is the evaluation board powered?
It should be powered externally using the EXTERNAL-1 and EXTERNAL-2 connectors.
What is the resistor tolerance of the AD5116?
The nominal resistor tolerance error is +8% maximum.
From: Analog Devices AD5116 Single-Channel 64-Position Digital Potentiometer Datasheet
What is the maximum wiper current?
The device supports a wiper current of +6 mA.
From: Analog Devices AD5116 Single-Channel 64-Position Digital Potentiometer Datasheet
