Analog Devices AD9910 Manuals

ManualLib has 3 documents for the Analog Devices AD9910 (Other Electronics): 2 datasheets, 1 user manual. Every file can be read online or downloaded as a PDF for free.

Datasheet 2User Manual 1

Key facts

Model
AD9910
Documents
3
Languages
ZH · EN
Last added
2026-10-23

Start here

ANALOG DEVICES UG-207 handbook

ANALOG DEVICES UG-207 handbook

User Manual 16 pages · 956 KB · EN

This user guide describes the setup and usage of the AD9910 evaluation board, which features a 1 GSPS Direct Digital Synthesizer (DDS) with a 14-bit DAC. The board includes PC evaluation software with a graphical user interface (GUI) that supports frequency sweep capabilities for device control and data analysis. It is designed to be factory tested and ready to use.

Read online

Analog Devices AD9910 specifications

Device Type1 GSPS DDS with 14-bit DAC
Operating SystemWindows 98/ME/2000/XP
ProcessorPentium I or later
Memory128 MB minimum
InterfaceUSB 1.1/2.0
Clock Input0 dBm up to 10 MHz

Source: ANALOG DEVICES UG-207 handbook

All Analog Devices AD9910 documents by type

Datasheet 2

Ratings, dimensions and ordering codes, for selection and design work.

User Manual 1

Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.

Questions answered in these manuals

What is the maximum internal clock speed of the AD9910?

The device supports an internal clock speed of up to 1 GSPS.

From: Analog Devices AD9910 1 GSPS Direct Digital Frequency Synthesizer Datasheet

What is the maximum frequency at which the AD9910 can generate frequency-hopping sine waves?

The device can generate frequency-hopping sine waves at frequencies up to 400 MHz.

From: Analog Devices AD9910 1 GSPS Direct Digital Frequency Synthesizer Datasheet

What are the power supply requirements for the evaluation board?

The board requires two independent DC voltages: 1.8 V and 3.3 V.

From: ANALOG DEVICES UG-207 handbook

How do I enable the USB control mode for the AD9910?

Set Jumpers W1, W2, and W4 to enable, and place jumpers on W3, W5, and W6.

From: ANALOG DEVICES UG-207 handbook

What is the maximum analog output frequency of the AD9910?

The AD9910 can generate an analog output up to 400 MHz.

From: Analog Devices AD9910 Direct Digital Synthesizer Data Sheet

What frequency resolution does the AD9910 provide?

It offers a frequency resolution of about 0.23 Hz.

From: Analog Devices AD9910 Direct Digital Synthesizer Data Sheet
