Analog Devices Motor Control Converters Portfolio Overview
This document highlights Analog Devices' portfolio of data converters designed for motor control applications, emphasizing higher performance, accuracy, and low power consumption. Key products include the AD7266, AD7400, AD7401, AD2S1200, and ADuC7000 series, which address challenges in current monitoring, optical encoder feedback, and resolver-to-digital conversion.
Read onlineAnalog Devices AD7401 specifications
| AD7266 Sampling Rate | 2 MSPS per ADC |
|---|---|
| AD7266 Resolution | 12-bit |
| AD7400 Data Rate | 10 MHz |
| AD7401 Data Rate | 18 MHz |
| AD7400 Isolation | 3.75 kV |
| AD2S1200 Accuracy | +11 arc minutes |
| AD2S1200 Tracking Rate | 1,000 rps |
Source: Analog Devices Motor Control Converters Portfolio Overview
All Analog Devices AD7401 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the maximum tracking rate of the AD2S1200?
The AD2S1200 has a maximum tracking rate of 1,000 rps with 12-bit resolution.
From: Analog Devices Motor Control Converters Portfolio Overview
What is the maximum throughput rate for the AD7266 ADC?
The AD7266 operates at a throughput of 2 MSPS per channel.
From: Analog Devices Motor Control Converters Portfolio Overview
What is the maximum external clock rate of the AD7401?
The AD7401 supports a maximum external clock rate of 20 MHz.
What isolation voltage does the AD7401 meet per UL 1577?
It meets a 5000 Vrms isolation voltage for a 1‑minute duration.
What is the maximum external clock rate for the AD7401?
The AD7401 supports a maximum external clock rate of 20 MHz.
What isolation voltage does the AD7401 meet under UL 1577?
It meets UL 1577 with an isolation voltage of 3750 Vrms for a 1‑minute test.
