Analog Devices Motor Control Converters Portfolio Overview
This document highlights Analog Devices' portfolio of data converters designed for motor control applications, emphasizing higher performance, accuracy, and low power consumption. Key products include the AD7266, AD7400, AD7401, AD2S1200, and ADuC7000 series, which address challenges in current monitoring, optical encoder feedback, and resolver-to-digital conversion.
Read onlineAnalog Devices AD7400 specifications
| AD7266 Sampling Rate | 2 MSPS per ADC |
|---|---|
| AD7266 Resolution | 12-bit |
| AD7400 Data Rate | 10 MHz |
| AD7401 Data Rate | 18 MHz |
| AD7400 Isolation | 3.75 kV |
| AD2S1200 Accuracy | +11 arc minutes |
| AD2S1200 Tracking Rate | 1,000 rps |
Source: Analog Devices Motor Control Converters Portfolio Overview
