ANALOG DEVICES PRD 1334 handbook
The document describes the ADP1047 300 Watt Evaluation Kit (PRD 1334), which features a boost power factor correction topology. The kit includes an evaluation board and software for interfacing with a PC via USB to control and monitor the internal registers of the ADP1047 chip.
Read onlineAnalog Devices ADP1047 specifications
| Rated Load | 300 W |
|---|---|
| Input Voltage Range | 85 Vrms to 265 Vrms |
| Output Voltage | 385 Vdc |
| Efficiency | 95 % |
| Switching Frequency | 97.7 KHz |
Source: ANALOG DEVICES PRD 1334 handbook
All Analog Devices ADP1047 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What software is required to control the evaluation board?
The ADP1047 GUI software allows control and monitoring of the internal registers via a USB connection.
How is communication established between the PC and the board?
Communication uses a 12C serial interface through a separate USB/I2C dongle.
What is the operating supply voltage range for the ADP1047?
The ADP1047 operates with a supply voltage between 3.0 V and 3.6 V.
How much EEPROM does the ADP1047 contain?
The device includes an 8 kB EEPROM for storing programmed values.
What supply voltage range does the ADP1047/ADP1048 operate from?
The devices operate from a 3.0 V to 3.6 V supply voltage (VDD).
From: Analog Devices ADP1047/ADP1048 Digital Power Factor Correction Controller Datasheet
How much EEPROM memory is available on the controller?
Each controller includes an 8 kB EEPROM for storing programmed values.
From: Analog Devices ADP1047/ADP1048 Digital Power Factor Correction Controller Datasheet
