Analog Devices AN-700 Application Note for AD9865/AD9866 Evaluation Software
This document provides installation instructions for the AD9865/AD9866 Evaluation Software, which requires the National Instruments LabVIEW Run-Time Engine version 5.1.1. It details the setup process for Windows 2000/NT and Windows 95/98, including unzipping files and running specific executables to install drivers and launch the graphical user interface (GUI).
Read onlineAnalog Devices AD9865 specifications
| DAC Resolution | 10 bits |
|---|---|
| DAC Update Rate | 200 MSPS |
| Full‑Scale Output Current (IOUTP_FS) | 2.25 mA |
| AVDD Supply Voltage Range | 3.135 V – 3.465 V |
| Maximum Total Supply Current | 475 mA |
| Tx DAC Gain Range | -75 dB to 0 dB |
| RxPGA Gain Range | -12 dB to +48 dB |
| Power Consumption (Full‑Duplex, Analog) | 311 mA – 342 mA |
Source: Analog Devices AD9865 Mixed‑Signal Front‑End Datasheet
All Analog Devices AD9865 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
How to use the product for one specific task, with worked examples.
Questions answered in these manuals
What software is required to run this evaluation tool?
You must install National Instruments' LabVIEW Run-Time Engine, version 5.1.1 on your PC.
From: Analog Devices AN-700 Application Note for AD9865/AD9866 Evaluation Software
What is the default SPI interface configuration for this software?
The default setting is a 3-wire SPI interface with MSB format.
From: Analog Devices AN-700 Application Note for AD9865/AD9866 Evaluation Software
What is the DAC resolution of the AD9865?
The AD9865 DAC provides a 10‑bit resolution.
From: Analog Devices AD9865 Mixed‑Signal Front‑End Datasheet
What is the maximum DAC update rate?
The DAC can update at up to 200 MSPS.
From: Analog Devices AD9865 Mixed‑Signal Front‑End Datasheet
What is the DAC update rate of the AD9865?
The DAC update rate is 200 MSPS.
What is the input voltage span at maximum RxPGA gain?
At a RxPGA gain of +48 dB, the input voltage span is 8 mV p‑p.
