Start here
Philips BT134 Series E Triac Datasheet
This datasheet describes the Philips BT134 series E, which consists of glass passivated, sensitive gate triacs packaged in a plastic SOT82 envelope. These devices are designed for use in general-purpose bidirectional switching and phase control applications where high voltage sensitivity is required in all four quadrants.
Read onlinePhilips BT134 specifications
| Repetitive peak off-state voltage (Vorm) | 500, 600 or 800 V |
|---|---|
| RMS on-state current (Irm) | 4 A |
| Operating junction temperature (Tj) | -125 °C |
| Storage temperature range | -40 to 150 C |
All Philips BT134 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
- Philips BT134 Series E Triac Datasheet 6 p
- Philips BT134 Series Triac Product Specification 6 p
- Philips BT134 Series E Triac Datasheet 6 p
- Philips BT134 Series D Logic Level Triac Product Specification 6 p
- Philips BT134 Series Triac Product Specification Datasheet 6 p
- Philips BT134 Series D Logic Level Triac Product Specification 6 p
Questions answered in these manuals
Are these devices suitable for all four quadrants?
Yes, they provide high voltage sensitivity in all four quadrants.
What is the net mass of the BT134 series E triac?
The net mass of the triac is 0.8 g.
What is the maximum operating junction temperature?
The maximum operating junction temperature is 125 °C.
Is the BT134 series suitable for life support applications?
No, these products are not designed for use in life support appliances or systems where malfunction can result in personal injury.
What is the package type for these triacs?
The triacs are in a plastic envelope with a SOT82 pin configuration.
What is the net mass of the SOT82 package?
The net mass of the package is 0.8 g.
