Start here
Philips HeartStart OnSite Defibrillator M5066A Owner's Manual
This document is the Owner's Manual for the Philips HeartStart OnSite Defibrillator, model M5066A. It serves as a guide for setting up, operating, maintaining, and managing accessories for the device. The manual covers the device's physical features, including the On/Off button, Information button, Caution light, and Shock button, as well as the SMART Pads Cartridge and battery installation.
Read onlinePhilips M5066A specifications
| Size | 7.2cm H x 19cm D x 21cm W |
|---|---|
| Weight | Approximately 1.5 kg |
| Operating Temperature | 0° to 50° C |
| Waveform Type | Biphasic truncated exponential |
| Shockable Rhythms | Ventricular fibrillation (VF) and some ventricular tachycardias |
| Shock Delivery Time | Within 8 seconds |
Source: Philips HeartStart OnSite Defibrillator M5066A Owner's Manual
All Philips M5066A documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the typical time to deliver a shock after a CPR interval?
The device can deliver a shock within 8 seconds, typical, following the prompt ending a CPR Interval.
From: Philips HeartStart OnSite Defibrillator M5066A Owner's Manual
What happens when the Caution light is on?
The Caution light is on when a shock is advised, reminding users that no one should be touching the patient.
From: Philips HeartStart OnSite Defibrillator M5066A Owner's Manual
How does the device indicate it is ready for use?
The Ready Light turns solid green when the device is in standby mode and ready for use.
From: Philips HeartStart OnSite Defibrillator M5066A Owner's Manual
What happens if the device needs attention?
The Caution Light flashes, and the device chirps while the i-button flashes to alert the user.
From: Philips HeartStart OnSite Defibrillator M5066A Owner's Manual
How do you turn the HeartStart OnSite on and off?
Press the green On/Off button to turn it on; to turn it off, press and hold the green button for one second.
From: Philips HeartStart OnSite Defibrillator M5066A Owner's Manual
