Philips X123 Computer Embroidery Machine Control System User Manual
This manual introduces the Philips X123 computer‑controlled embroidery machine, covering safety precautions, hardware components, user interface, and detailed operating procedures. It is organized into sections that guide users from basic setup and pattern selection to advanced functions such as gold‑foil stitching and parameter management.
The document also includes troubleshooting tables, parameter tables, and appendices with error codes and maintenance tips, helping both operators and service technicians keep the machine running safely and efficiently. This manual is written in Chinese.
Philips X123 specifications
| Power supply voltage | 380 V three‑phase or 220 V single‑phase AC |
|---|---|
| Frequency | 50 Hz / 60 Hz |
| Maximum power capacity | 1.5 kW (≤10 heads) / 2.1 kW (>10 heads) |
| Operating temperature range | 5 °C – 40 °C |
| Relative humidity range | 30 % – 95 % |
| Maximum ground resistance | ≤ 10 Ω |
| Ground wire cross‑section | ≥ 4 mm² copper stranded wire |
| Minimum clearance from wall | ≥ 60 cm |
Source: Philips X123 Computer Embroidery Machine Control System User Manual
All Philips X123 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
How long should I charge the built‑in battery before first use?
Charge the built‑in battery for at least 3 hours before using the projector for the first time.
What is the recommended projection distance?
The projector works best when placed between 0.2 m and 3 m from the screen.
