Philips Semiconductors BT139X Series Triac Datasheet
This document provides a product specification for the BT139X series of passivated triacs in a full pack plastic envelope. These devices are designed for applications requiring high bidirectional transient and blocking voltage capability, such as motor control, industrial lighting, heating, and static switching.
The datasheet details general descriptions, quick reference data, limiting values, isolation limits, thermal resistances, static characteristics (including gate trigger current and latching current), dynamic characteristics, and mechanical dimensions for the SOT186A package.
All Philips BT139X documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the package type for the BT139X series?
The triacs are in a full pack, plastic envelope with SOT186A pinning.
How much thermal resistance exists from junction to heatsink without compound?
The thermal resistance is 5.5 K/W when no heatsink compound is used.
