Start here
Philips VTR840 Audio/Video Recorder User Manual
This manual introduces the Philips VTR840 audio/video recorder, highlighting its one‑key recording, video, playback and built‑in intercom functions. It guides users through safety precautions, charging, and basic operation such as powering on, switching modes, and using the USB interface.
Detailed sections cover recording, video capture, photo mode, voice playback, intercom settings, and a comprehensive FAQ. The technical parameters list storage options, dimensions, supported operating systems, audio quality, and environmental limits. This manual is written in Chinese.
Philips VTR840 specifications
| External storage capacity (recording time) | ≈86 hours for 16 GB |
|---|---|
| Maximum external storage card | 128 GB |
| Internal storage type | C10 TF card |
| Dimensions (W×H×D) | 58 mm × 100 mm × 26 mm |
| Weight (with battery) | 203 g |
| Supported operating systems | Windows, macOS, Linux |
| High‑quality audio bitrate | 1536 kbps WAV |
| Operating temperature range | -30 °C to +55 °C |
| Relative humidity range | 10 % – 90 % (non‑condensing) |
All Philips VTR840 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
How do I turn the VTR840 on and off?
Press and hold the power key for 3 seconds to turn the device on; press and hold the same key for 3 seconds to turn it off.
What is the maximum size of the external memory card I can use?
The recorder supports external memory cards up to 128 GB.
How do I turn the VTR840 on and off?
Press and hold the power button for 2–3 seconds to turn the device on or off; a green light indicates power‑on, and the orange light shows charging.
From: Philips VTR840 VoiceTracer Audio Video Recorder User Manual
What type of memory card is required for recording?
The recorder needs a MicroTF (micro‑SD) card with a capacity between 4 GB and 32 GB, formatted before use.
From: Philips VTR840 VoiceTracer Audio Video Recorder User Manual
