Agilent 490 Micro-GC Biogas Analyzer User Manual
The Agilent 490 Micro-GC Biogas Analyzer is a factory-configured instrument designed for the analysis of pure biogas, permanent gases, hydrogen sulfide, and hydrocarbons up to n-propane. The system consists of a dual housing equipped with a CP-Molsieve 5A and a CP-PoraPLOT U column for two carrier gases. An extended version is also available for analyzing mixtures of biogas and other hydrocarbon streams up to n-heptane. This manual is written in German.
Read onlineAgilent 490 Micro GC specifications
| Number of column channels (Analyzer A) | 2 |
|---|---|
| Repeatability (RSD%) | < 0.5% |
| Typical analysis time (until C6) | 75 s |
| Sample inlet treatment | UltiMetal treated |
| Heated sample line temperature | up to 110 °C |
All Agilent 490 Micro GC documents by type
Ratings, dimensions and ordering codes, for selection and design work.
How to use the product for one specific task, with worked examples.
- Agilent 490 Micro GC Application Note: Permanent Gases on a COX Module 4 p
- Analysis of Acetone n-Hexane MIBK MNBK MIBC Using the Agilent 490 Micro GC Application Note 2 p
- Agilent 490 Micro GC Permanent Gas Analysis Application Note 2 p
- Agilent 490 Micro GC Application Note: Fast Separation of Oxygen and Nitrogen on MolSieve 5A Channel 2 p
- Agilent 490 Micro GC Application Note for Tetrahydrothiophene Analysis 2 p
- Agilent 490 Micro GC Analysis of Volatile Solvents on CP-Sil 5 CB Application Note 2 p
- Agilent 490 Micro GC Application Note for MES Analysis in Natural Gas 2 p
- Agilent 490 Micro GC Application Note for Acetone, Methanol, and Ethanol Analysis in Air 2 p
- Agilent 490 Micro GC C1-C3 Hydrocarbon Analysis Application Note 2 p
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the typical analysis time for C6 hydrocarbons?
The typical analysis time until C6 is 75 seconds.
Is software available for calorific value calculations?
Yes, the EZReporter software is available as an option for calculating heating values and BTU.
What is the main difference between the standard and extended biogas analyzers?
The extended analyzer includes an additional channel for analyzing higher boiling hydrocarbons like C4 to C7.
Is the analyzer ready to use out of the box?
Yes, it ships fully loaded with a method and is ready-to-go upon installation.
What are the repeatability figures for the analyzed components?
The repeatability figures per component on peak area are: He (0.43%), H2 (0.47%), N2+O2 (0.47%), CO (0.64%), CH4 (0.33%), and CO2 (0.51%).
From: Agilent 490 Micro GC Application Note: Permanent Gases on a COX Module
Does the CP-COX column separate oxygen and nitrogen?
No, the CP-COX column does not separate oxygen and nitrogen; they elute as a single peak.
From: Agilent 490 Micro GC Application Note: Permanent Gases on a COX Module
