Key facts
- Brand
- Agilent
- Model
- 5975 MSD
- Documents
- 4
- Languages
- EN · IT · ZH
- Last added
- 2012-07-05
Start here
Agilent 5975 MSD Series GC/MSD Operating Manual
This document is the operating manual for the Agilent 5975 MSD Series Gas Chromatography/Mass Spectrometry (GC/MSD) system. It provides comprehensive instructions for users on how to operate the instrument in both Electron Impact (EI) and Chemical Ionization (CI) modes. The guide includes detailed procedures for hardware setup, safety precautions, and daily operational tasks. This manual is written in Italian.
Read onlineAgilent 5975 MSD specifications
| Mass Range (MSD) | up to 1050 Daltons |
|---|---|
| Ion Source Temperature (MSD) | 300°C |
| Quadrupole Temperature (MSD) | 150°C |
| Wavelength Range (UV-Vis) | 190 to 1100 nm |
| Stray Light (UV-Vis) | less than 0.03 % |
Source: Agilent Technologies WEEE/RoHS/ELV Compliance Brochure
All Agilent 5975 MSD documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the maximum heating rate for Fast GC analysis using the LTM module?
The Agilent Low Thermal Mass (LTM) module supports a heating rate of up to 1200 C/min.
How many different columns can the LTM module control independently?
The system allows for independent temperature control of up to 4 different columns.
What hazardous substances are restricted by RoHS/ELV regulations?
The regulated substances include cadmium (Cd), mercury (Hg), lead (Pb), hexavalent chromium (Cr(VI)), and brominated flame retardants (BFRs).
From: Agilent Technologies WEEE/RoHS/ELV Compliance Brochure
What are the EU limits for Lead (Pb)?
The EU limit for Lead in finished materials is 1000mg/kg (0.1%).
From: Agilent Technologies WEEE/RoHS/ELV Compliance Brochure
What does this manual cover regarding the GC/MSD system?
This manual provides information on the operation and maintenance of the Agilent MSD series 5975 GC/MSD system.
What safety warning indicates a risk of personal injury or loss of life?
The AVVERTENZA notice indicates conditions that, if not followed correctly, could cause serious personal injuries or loss of life.
