Agilent 490 Micro GC Natural Gas Analyzer is a high-performance natural gas analyzer launched by Agilent. The instrument can quickly and accurately analyze the components of natural gas.
The Agilent 490 Micro GC Natural Gas Analyzers are factory-tuned solutions designed for analyzing natural gas composition and heating value. The system utilizes micro-gas chromatography to provide precise results in seconds rather than minutes, suitable for both laboratory and field applications.
Available configurations include the Natural Gas Analyzer A (Dual channel) and B (Quad channel), as well as Extended versions with additional column channels. Key features include heated sample lines, electronic carrier gas control, and optional software for calorific value calculations.
| Number of column channels (Analyzer A) | 2 |
|---|---|
| Repeatability (RSD%) | < 0.5% |
| Typical analysis time (until C6) | 75 s |
| Sample inlet treatment | UltiMetal treated |
| Heated sample line temperature | up to 110 °C |
The typical analysis time until C6 is 75 seconds.
Yes, the EZReporter software is available as an option for calculating heating values and BTU.
Yes, it can handle ambient pressure to 68 bar/1000 psi using internal sample pump or continuous flow.
