Start here
Analog Devices ADSP-2189M EZ‑KIT Lite Evaluation System Manual
This manual guides programmers in using the ADSP-2189M EZ‑KIT Lite evaluation system, covering hardware installation, software setup with VisualDSP++, and debugging procedures. It is intended for users familiar with Analog Devices DSP architecture and those new to the platform.
The board features the ADSP-2189M processor, AD73322 stereo codec, RS‑232 interface, and various analog I/O. Power is supplied by a 7.5 V DC source, and the system can be accessed from a PC via serial port or an optional EZ‑ICE emulator for in‑circuit debugging.
Analog Devices ADSP-2189M specifications
| Instruction Cycle Time | 13.3 ns @ 2.5 Volts (Internal) |
|---|---|
| Sustained Performance | 75 MIPS |
| On-Chip Program Memory | 32K words (24-bit) |
| On-Chip Data Memory | 48K words (16-bit) |
| Package Type | 100-lead LQFP |
Source: Analog Devices ADSP-2189M DSP Microcomputer Datasheet
All Analog Devices ADSP-2189M documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the instruction cycle time of the ADSP-2189M?
The instruction cycle time is 13.3 ns when operating at 2.5 Volts internally.
Does the ADSP-2189M support single-cycle instruction execution?
Yes, every instruction can execute in a single processor cycle.
What power does the EZ‑KIT Lite board require?
It needs a 7.5 V DC supply with a maximum current of 4 A.
From: Analog Devices ADSP-2189M EZ‑KIT Lite Evaluation System Manual
Which audio codec is used on the evaluation board?
The board uses the AD73322 stereo codec.
From: Analog Devices ADSP-2189M EZ‑KIT Lite Evaluation System Manual
