Analog Devices SHARC Processors Core PLL Management Application Note
This document explains how to program the core phase-locked loop (PLL) on ADSP-2126x, ADSP-2136x, ADSP-2137x, ADSP-2146x, ADSP-2147x, and ADSP-2148x SHARC processors. It details the use of the Power Management Control Register (PMCTL) to select core clock (CCLK) to input clock (CLKIN) ratios dynamically in software, offering power savings and flexibility beyond hardware pin limitations. The note includes block diagrams for various processor families illustrating input dividers, multipliers, and output dividers.
Read onlineAnalog Devices ADSP-2146x) specifications
| Max CCLK for ADSP-2126x | 200 MHz |
|---|---|
| Max CCLK for ADSP-21368 | 400 MHz |
| Max CCLK for ADSP-2146x | 450 MHz |
| PLL Lock Time | 4096 CCLK cycles |
| Divider Effect Time | 16 CCLK cycles |
| VCO Frequency Formula | fVCO = 2 * PLLM * fINPUT |
Source: Analog Devices SHARC Processors Core PLL Management Application Note
