Analog Devices ADSP-BF549 Processor Data Sheet

Analog Devices ADSP-BF549 Processor Data Sheet

Datasheet 100 pages · 3.4 MB · EN

This datasheet describes the ADSP-BF549 Blackfin processor, a high-performance embedded processor with up to 600 MHz clock speed and dual-MAC signal processing. It includes memory architecture, DMA controllers, peripherals like USB OTG, SD/SDIO, CAN, UARTs, and secure features such as Lockbox code security. The document covers electrical characteristics, timing, and package details for design and integration.

Read online

Analog Devices ADSP-BF549 specifications

Clock SpeedUp to 600 MHz
MemoryUp to 324K bytes of on-chip memory
Package400-ball CSP_BGA, RoHS compliant
Core Instruction Rate533 MHz or 600 MHz
Secure TechnologyLockbox code security with 128-bit AES/ARC4 encryption
