Start here
ANALOG DEVICES ADSP-218x DSP family ADSP-2192 EZ-KIT Lite Installation Procedure -Non-USB (Rev 3.2) Manual
The guide provides step‑by‑step instructions for preparing the EZ‑KIT Lite evaluation system, including checking the package contents, installing the VisualDSP++ development environment, and configuring the hardware connections.
It also outlines how to create a new debugging session in VisualDSP++, select the appropriate ADSP‑218x processor, and run example programs. A brief warranty statement is included at the end. This manual is written in Chinese.
Analog Devices ADSP-218X specifications
| Address Space | 20 Bits |
|---|---|
| Overhead per DM word | Approx. 8 cycles |
| Max DM words per block | 256 words |
| Max PM words per block | 170 words |
| Processor Pin Count | 100 pin |
Source: ANALOG DEVICES BDMA Usage on 100 pin ADSP-218x DSPs Configured for IDMA Use Manual
All Analog Devices ADSP-218X documents by type
Instruction set, parameters and examples for configuring or programming the device.
How to use the product for one specific task, with worked examples.
- Analog Devices ADSP-218x I/O Space Application Note 5 p
- Analog Devices ADSP-218x Converting Legacy Architecture Files To Linker Description Files 18 p
- Analog Devices ADSP-218x Embedded System Software Management ISP Manual 2 p
- Analog Devices ADSP-218x Mode D Pin Compatibility FAQ 2 p
- Analog Devices ADSP-218x External Overlay Memory Technical Note 2 p
- ANALOG DEVICES BDMA Usage on 100 pin ADSP-218x DSPs Configured for IDMA Use Manual 7 p
- Analog Devices EE-39 Interfacing Byte Programmed Flash Memories to the ADSP-218x 13 p
- ANALOG DEVICES EE-5 ADSP-218x Full Memory Mode vs. Host Memory Mode Manual 2 p
- ANALOG DEVICES EE-146 Implementing a Boot Manager for ADSP-218x Family DSPs Manual 8 p
- ANALOG DEVICES EE-249 Manual 6 p
Disassembly, diagnostics and part numbers, for repair.
The shortest path to a working setup, usually only a few pages.
Questions answered in these manuals
What is the main advantage of ADSP-218x I/O space?
It allows parallel-peripheral I/O without additional decoding hardware.
How do you access an I/O address in assembly language?
Use the syntax Dreg = IO(address) to read and IO(address) = Dreg to write.
What VisualDSP version is required to use the linker description files described in this note?
The document explains how to describe hardware memory architecture using VisualDSP version 7.0.
From: Analog Devices ADSP-218x Converting Legacy Architecture Files To Linker Description Files
What data width must be declared for Program Memory segments in an LDF file?
Program Memory segments must be declared as 24 bits using the WIDTH(24) LDF command.
From: Analog Devices ADSP-218x Converting Legacy Architecture Files To Linker Description Files
What is the baud rate and parity for the ASCII terminal connection?
The connection requires an ASCII terminal at 9600,N,8,1 (9600 baud, no parity, 8 data bits, 1 stop bit).
From: Analog Devices ADSP-218x Embedded System Software Management ISP Manual
Which command erases FLASH sectors?
The <SE> command is used to erase destination sectors of the FLASH memory.
From: Analog Devices ADSP-218x Embedded System Software Management ISP Manual
