STMicroelectronics TS2007FC Class-D Audio Power Amplifier Datasheet
The TS2007FC is a class-D power audio amplifier designed to drive up to 1.4 W into an 8 Ω load at 5 V or 2.3 W into a 4 Ω load. It features two fixed gain settings of 6 dB or 12 dB, selectable via a logic signal on the GS pin.
Read onlineSTMicroelectronics TS2007FC specifications
| Supply voltage range | 2.4 V to 5.5 V |
|---|---|
| Gain settings | 6 dB or 12 dB |
| Efficiency (typical) | 86% |
| Signal-to-noise ratio | 90 dB typical |
Source: STMicroelectronics TS2007FC Class-D Audio Power Amplifier Datasheet
All STMicroelectronics TS2007FC documents by type
Ratings, dimensions and ordering codes, for selection and design work.
How to use the product for one specific task, with worked examples.
Questions answered in these manuals
What is the operating temperature range?
The device operates from -40 to +85 °C.
From: STMicroelectronics TS2007FC Class-D Audio Power Amplifier Datasheet
Does the amplifier have thermal shutdown protection?
Yes, it is protected by a thermal shutdown active at 150°C.
From: STMicroelectronics TS2007FC Class-D Audio Power Amplifier Datasheet
What is the order code for the TS2007FC demonstration board?
The order code for the board online is STEVAL-CCA012V1.
From: STMicroelectronics AN2862 TS2007FC Demo Board User Guidelines
How is the gain of the TS2007FC selected on the evaluation board?
The gain can be set to either 6 or 12 dB via the P1 connector.
From: STMicroelectronics AN2862 TS2007FC Demo Board User Guidelines
