Philips TDA1308 Class AB Stereo Headphone Driver Datasheet
This document is a product specification datasheet for the TDA1308, an integrated Class AB stereo headphone driver designed for portable digital audio applications. The device is available in SO8 and DIP8 plastic packages and features a wide temperature range, short-circuit resistance, and low power consumption.
Read onlinePhilips TDA1308 specifications
| Supply Voltage (Single) | 3.0 to 7.0 V |
|---|---|
| Signal-to-Noise Ratio | 100 to 110 dB |
| Total Power Dissipation | 15 to 25 mW |
| Package Types | SO8, DIP8 |
Source: Philips TDA1308 Class AB Stereo Headphone Driver Datasheet
All Philips TDA1308 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the primary application for the TDA1308?
The device has been primarily developed for portable digital audio applications.
From: Philips TDA1308 Class AB Stereo Headphone Driver Datasheet
Is the TDA1308 short-circuit resistant?
Yes, the device is short-circuit resistant.
From: Philips TDA1308 Class AB Stereo Headphone Driver Datasheet
What is the difference between TDA1308 and TDA1308A?
The TDA1308A can be used at low supply voltages.
From: Philips TDA1308/TDA1308A Class AB Stereo Headphone Driver Datasheet
What is the maximum operating ambient temperature for the TDA1308 and TDA1308A?
The device can operate in an ambient temperature range of -40 to +85 °C.
From: Philips TDA1308/TDA1308A Class AB Stereo Headphone Driver Datasheet
Is the TDA1308 short-circuit resistant?
Yes, the device is short-circuit resistant.
From: Philips TDA1308 Class AB Stereo Headphone Driver Datasheet
What is the TDA1308?
The TDA1308 is an integrated class AB stereo headphone driver contained in an SO8 or a DIP8 plastic package.
From: Philips TDA1308 Class AB Stereo Headphone Driver Datasheet
