The TDA1308 is an integrated class AB stereo headphone driver from Philips Semiconductors that comes in an SO8 or DIP8 plastic package. The device is fabricated in a 1μm CMOS process and has been primarily developed for portable digital audio applications.
The Philips TDA1308 is an integrated Class AB stereo headphone driver designed primarily for portable digital audio applications. It is fabricated in a 1 µm CMOS process and is available in SO8 or DIP8 plastic packages. Key features include excellent power supply ripple rejection, low power consumption, and short-circuit resistance.
| Supply Voltage (Single) | 3.0 to 7.0 V |
|---|---|
| Signal-to-Noise Ratio | 100 to 110 dB |
| Package Types | DIP8, SO8 |
Yes, the device is short-circuit resistant.
The TDA1308 is an integrated class AB stereo headphone driver contained in an SO8 or a DIP8 plastic package.
The device can operate in an ambient temperature range from -40 to +85 °C.
The maximum supply voltage is 8.0 V.
