Start here
Analog Devices ADM1068 Handbook
The ADM1068 Super Sequencer and Monitor is a configurable supervisory and sequencing device for up to eight supplies. It provides fault detection, programmable driver outputs, and an SMBus interface for configuration. The handbook details the device’s functional block diagram, pin assignments, and typical performance characteristics.
Key sections cover specifications, absolute maximum ratings, thermal resistance, ESD precautions, power supply requirements, and programming procedures for supply fault detectors. An ordering guide and package dimensions are also included.
Analog Devices ADM1068 specifications
| Maximum VDDCAP | 5.1 V |
|---|---|
| Reference Output Voltage | 2.048 V |
| Operating Temperature Range | -40°C to +85°C |
| Package Type | 32-lead 7 mm x 7 mm LQFP |
| Clock Frequency | 100 kHz |
Source: Analog Devices ADM1068 Super Sequencer and Monitor Datasheet
All Analog Devices ADM1068 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the maximum voltage the ADM1068 can monitor on the VH pin?
The device can monitor supplies up to 14.4 V on the VH pin.
From: Analog Devices ADM1068 Super Sequencer and Monitor Datasheet
How many programmable output drivers does the ADM1068 have?
The device features eight programmable output drivers (PDO1-8).
From: Analog Devices ADM1068 Super Sequencer and Monitor Datasheet
What is the supply voltage range for the VH pin?
The VH pin operates from 3.0 V up to 14.4 V.
How many programmable driver outputs does the ADM1068 provide?
It provides eight programmable driver outputs, labeled PDO1 through PDO8.
What is the voltage range for the high‑voltage input (VH) on the ADM1068?
The VH pin accepts voltages from 3.0 V to 14.4 V.
How many programmable driver outputs does the ADM1068 provide?
The device provides eight programmable driver outputs, labeled PDO1 to PDO8.
