Analog Devices ADM1066 User Manual
The ADM1066 Super Sequencer is a configurable supervisory and sequencing device that monitors up to ten supplies, integrates a 12‑bit ADC, six 8‑bit DACs, and a programmable sequencing engine. It supports margining control, fault detection, and SMBus communication, allowing both closed‑loop and open‑loop supply adjustment.
The manual includes functional block diagrams, detailed pin descriptions, electrical specifications, programming guidelines, and ordering information for the 40‑lead LFCSP and 48‑lead TQFP packages. It also covers absolute maximum ratings, thermal resistance, and ESD precautions to ensure reliable operation in multivoltage system applications.
Analog Devices ADM1066 specifications
| Number of Supplies Supported | Up to 10 supplies |
|---|---|
| Supply Fault Detector Accuracy | Better than 1% |
| ADC Resolution | 12 Bits |
| DAC Resolution | 8 Bits |
| Package Options | 40-lead LFCSP and 48-lead TOQFP |
| Interface Type | SMBus |
Source: Analog Devices ADM1066 Super Sequencer with Margining Control Datasheet
All Analog Devices ADM1066 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the maximum number of supplies the ADM1066 can supervise?
The device supports supervision for up to 10 supplies.
From: Analog Devices ADM1066 Super Sequencer with Margining Control Datasheet
How many programmable output drivers does the ADM1066 have?
It has 10 programmable output drivers (PDO1-10).
From: Analog Devices ADM1066 Super Sequencer with Margining Control Datasheet
What voltage range does the VH pin accept?
The VH pin operates from 3.0 V up to 14.4 V.
How many programmable driver outputs are available?
The device provides ten programmable driver outputs, labeled PDO1 through PDO10.
What is the maximum supply voltage for the VH pin?
The VH pin can be operated up to 14.4 V.
How many ADC channels does the ADM1066 provide?
The device includes a 12‑bit SAR ADC with up to 12 channels that can be read back.
