Key facts
- Brand
- Texas Instruments
- Model
- TAS1020A
- Industry
- Industrial
- Documents
- 3
- Languages
- EN
- Last added
- 2012-08-01
Start here
texas instruments TAS1020A handbook1
User Manual 11 pages · 376 KB · EN
The Extech SDL200 is a 4-channel thermometer and datalogger designed to display and store temperature readings from up to four thermocouple probes (Types K, J, T, E, R, or S) and two Pt100 RTD probes. The device allows for data logging to an SD card and data streaming via an RS232 port to a PC. It is shipped fully tested and calibrated for reliable service.
Read onlineTexas Instruments TAS1020A specifications
| Thermocouple Inputs | up to four (4) |
|---|---|
| RTD Inputs | two (2) |
| Thermocouple Types Supported | K, J, T, E, R, or S |
| RTD Type Supported | Pt100 |
| Thermocouple Range | -20 to +250°C |
| Power Source | six (6) 1.5VDC 'AA' batteries or optional AC adaptor |
| Auto Power OFF Delay | 10 minutes |
All Texas Instruments TAS1020A documents by type
Datasheet 3
Ratings, dimensions and ordering codes, for selection and design work.
User Manual 1
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the usable temperature range for the supplied thermocouple probes?
The supplied thermocouple probes are usable in the range of -20 to +250°C (-4 to +482°F).
How do I access the Setup menu?
Press and hold the SET button for at least 1.5 seconds to access the Setup menu.
