Texas Instruments CDC328 1-Line to 6-Line Clock Driver Datasheet
The CDC328 is a 1-line to 6-line clock driver designed for clock distribution and generation applications. It features selectable polarity control to obtain various combinations of true and complementary outputs, minimizing skew between distributed signals. The device utilizes an EPIC-IIB BiCMOS design to significantly reduce power dissipation.
Read onlineAll Texas Instruments CDC328 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the function of the CDC328?
The CDC328 contains a clock-driver circuit that distributes one input signal to six outputs with minimum skew.
From: Texas Instruments CDC328 1-Line to 6-Line Clock Driver Datasheet
How does the polarity control work?
Through the use of the polarity-control inputs (T/C), various combinations of true and complementary outputs can be obtained.
From: Texas Instruments CDC328 1-Line to 6-Line Clock Driver Datasheet
What is the operating temperature range for the CDC328A?
The device is characterized for operation from -40°C to 85°C.
From: Texas Instruments CDC328A 1-Line to 6-Line Clock Driver Datasheet
What is the maximum input clock frequency?
The maximum input clock frequency is 100 MHz.
From: Texas Instruments CDC328A 1-Line to 6-Line Clock Driver Datasheet
