Start here
TEXAS INSTRUMENTS SN65LVDS32B SN65LVDT32B SN65LVDS3486B SN65LVDT3486B SN65LVDS9637B SN65LVDT9637B Manual
The SN65LVDS and SN65LVDT families are high‑speed differential line receivers that operate from a single 3.3 V supply. They meet ANSI/TIA‑644 standards, provide integrated 110 Ω line‑termination, and include a fail‑safe circuit that drives a high‑level output within 600 ns after loss of the input signal.
The devices are offered in small‑outline packages, support a wide common‑mode input range (‑2 V to +5 V), and are rated for operation from –40 °C to 85 °C. Electrical and switching characteristics such as propagation delay, output skew, and ESD protection are detailed in the datasheet.
Texas Instruments SN65LVDS34 specifications
| Supply voltage range | 3.0 V – 3.6 V |
|---|---|
| Operating temperature range | ‑40 °C – 85 °C |
| Integrated line‑termination resistance | 110 Ω |
| Propagation delay (low‑to‑high output) | 2.5 ns – 6 ns |
| ESD protection (HBM) | 15 kV |
All Texas Instruments SN65LVDS34 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What supply voltage does the SN65LVDS series require?
The devices operate from a single 3.3 V supply with a permissible range of 3.0 V to 3.6 V.
What is the propagation delay of the receiver outputs?
Typical propagation delay is 2.5 ns to 6 ns for both low‑to‑high and high‑to‑low transitions.
What electrostatic discharge levels can the receivers withstand?
The receivers can withstand +15 kV human‑body model (HBM) and +600 V machine model (MM) discharges to the input pins.
From: Texas Instruments SN65LVDS33/ SN65LVDT33/ SN65LVDS34/ SN65LVDT34 Datasheet
What is the recommended supply voltage range for these devices?
The recommended supply voltage (Voc) is 3.3 V to 3.6 V.
From: Texas Instruments SN65LVDS33/ SN65LVDT33/ SN65LVDS34/ SN65LVDT34 Datasheet
