Start here
Texas Instruments TMS320VC5410A Fixed-Point DSP Data Manual
The TMS320VC5410A data manual provides detailed information on the fixed‑point DSP, including functional overview, electrical specifications, on‑chip peripherals, DMA controller, and multichannel buffered serial port details. It also lists pin assignments for the GGU BGA and PGE LQFP packages and presents the memory map for program, data, and extended program memory.
Mechanical data, package thermal resistance characteristics, and revision history are included, with dimensions given in millimetres. The document is intended for designers and engineers who need precise electrical and mechanical parameters for system integration.
Texas Instruments TMS320VC5410A specifications
| Literature Number | SPRS139G |
|---|---|
| Package Type (LQFP) | 144‑Pin PGE Low‑Profile Quad Flatpack |
| Package Type (BGA) | 144‑Ball GGU MicroStar BGA |
| Revision Date | January 2005 |
Source: Texas Instruments TMS320VC5410A Fixed-Point DSP Data Manual
All Texas Instruments TMS320VC5410A documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the literature number for the TMS320VC5410A data manual?
The literature number is SPRS139G.
From: Texas Instruments TMS320VC5410A Fixed-Point DSP Data Manual
When was the data manual last revised?
It was revised in January 2005.
From: Texas Instruments TMS320VC5410A Fixed-Point DSP Data Manual
What is the literature number for the TMS320VC5410A data manual?
The literature number is SPRS139G.
From: Texas Instruments TMS320VC5410A Fixed-Point DSP Data Manual
When was the TMS320VC5410A data manual last revised?
It was revised in January 2005 (originally published November 2000).
From: Texas Instruments TMS320VC5410A Fixed-Point DSP Data Manual
