Key facts
- Brand
- Texas Instruments
- Model
- S2000
- Category
- Other device
- Industry
- Industrial
- Documents
- 2
- Languages
- EN
- Last added
- 2026-09-29
Start here
Texas Instruments S2000 Reader Configuration Manual
The document provides step‑by‑step instructions for establishing a USB connection to the S2000 Reader and modifying its EEPROM settings. It is intended for engineers familiar with RFID devices and covers driver installation, HyperTerminal setup, and parameter configuration.
Key procedures include creating the installer folder, installing the TI USB drivers, connecting the reader with jumper J11 in place, and using Windows HyperTerminal to read or write EEPROM values. Default EEPROM values are listed in Appendix A, and the required dipswitch setting for configuration is described.
Texas Instruments S2000 specifications
| RF Transmit Frequency | 134.2 kHz |
|---|---|
| Operating Temperature | 0 to +50 °C |
| Storage Temperature | -25 to +85 °C |
| Logic Supply Voltage | 4.75 to 5.25 VDC |
| Power Supply TX Power Stage | 4.50 to 6.00 VDC |
| Antenna Inductance Range | 115 to 117uH |
| Dimensions | 60.2 x 55.1 x 11.5 mm |
| Weight | approx. 40 g |
Source: Texas Instruments RI-RFM-003B Series 2000 Mini RF Module Datasheet
All Texas Instruments S2000 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
How do I install the USB drivers for the S2000 Reader?
Extract the installer folder and run the setup.exe file; the drivers will be installed automatically.
What transponder types does this module support?
The module supports 134.2 kHz HDX / FSK transponders.
From: Texas Instruments RI-RFM-003B Series 2000 Mini RF Module Datasheet
What is the maximum antenna resonance voltage?
The maximum antenna resonance voltage is 240 V peak.
From: Texas Instruments RI-RFM-003B Series 2000 Mini RF Module Datasheet
