Texas Instruments SN54F10 SN74F10 Triple 3-Input NAND Gate Datasheet
The SN54F10 and SN74F10 are triple 3‑input positive‑NAND gate integrated circuits offered in multiple package options, including plastic, small‑outline, and ceramic variants. Each device contains three independent NAND gates that implement the Boolean function Y = A·B·C in positive logic.
The document provides absolute maximum ratings, recommended operating conditions, electrical and switching characteristics, and legal notices. Key parameters such as supply voltage, input thresholds, output currents, and temperature ranges are specified for both the SN54F10 (‑55 °C to 125 °C) and SN74F10 (0 °C to 70 °C).
Texas Instruments SN54F10 specifications
| Supply voltage range (VCC) | –0.5 V to 7 V |
|---|---|
| Input voltage range (VI) | –1.2 V to 7 V |
| Operating temperature (SN54F109) | –55 °C to 125 °C |
Source: Texas Instruments SN54F109 / SN74F109 Dual J‑K Flip‑Flop Datasheet
All Texas Instruments SN54F10 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
Which package types are available for the SN54F10?
Package options include plastic SN54F10, J‑package, small‑outline, ceramic chip carriers, and standard DIP packages.
From: Texas Instruments SN54F10 SN74F10 Triple 3-Input NAND Gate Datasheet
What temperature range can the SN54F109 operate in?
The SN54F109 is specified for operation from –55 °C to 125 °C.
From: Texas Instruments SN54F109 / SN74F109 Dual J‑K Flip‑Flop Datasheet
What is the supply voltage range for these flip‑flops?
The devices can be powered with a supply voltage between –0.5 V and 7 V.
From: Texas Instruments SN54F109 / SN74F109 Dual J‑K Flip‑Flop Datasheet
