Texas Instruments XIO3130 Manuals

Key facts

Brand: Texas Instruments
Model: XIO3130
Category: Other Electronics
Documents: 2
Languages: EN
Last added: 2012-06-05

Start here

Texas Instruments XIO2000A/XIO2200A/XIO3130/XIO1100/PCIE412 PCI Express Solutions Datasheet

Datasheet 9 pages · 766 KB · EN

This document provides technical data sheets for several Texas Instruments PCI Express solutions, including the XIO2000A bridge chip, the XIO2200A 1394a bridge, the XIO3130 fan-out switch, the XIO1100 PHY, and the PCIE412 mux switch. It details their specifications, key features, target markets, and part numbers.

Read online

Texas Instruments XIO3130 specifications

PCI Express Rate Support	2.5 Gbps
Secondary PCI Bus Width	32-bit
Package Type (XIO2000A)	MicroStar BGA
1394a Cable Ports Speeds	100, 200 and 400 Mbps
Package Type (XIO3130)	MicroStar BGA
Signal Processing Bandwidth (PCIE412)	2.5 Gbps

Source: Texas Instruments XIO2000A/XIO2200A/XIO3130/XIO1100/PCIE412 PCI Express Solutions Datasheet

All Texas Instruments XIO3130 documents by type

Datasheet 2

Ratings, dimensions and ordering codes, for selection and design work.

Questions answered in these manuals

What are the target markets for the XIO2000A?

Target markets include desktop and mobile PC, server, storage, PC add-in cards, and embedded systems.

From: Texas Instruments XIO2000A/XIO2200A/XIO3130/XIO1100/PCIE412 PCI Express Solutions Datasheet

Is the XIO3130 compliant with PCI Express Base Specification Revision 1.1?

Yes, it is fully compliant with PCI Express Base Specification, Revision 1.1.
