TEXAS INSTRUMENTS TPA6104A2 Data Sheet
Datasheet 19 pages · 500 KB · EN
The TPA6101A2 is a stereo audio power amplifier designed for battery applications, capable of delivering 50 mW of continuous RMS power per channel into 16-Ω loads. It features an ultralow supply voltage range from 1.6 V to 3.6 V and includes gain set internally to 2 dB (inverting) to minimize external component requirements.
Read onlineTexas Instruments TPA6101A2 specifications
| Supply Voltage Range | 1.6 V to 3.6 V |
|---|---|
| Output Power (per channel) | 50 mW into 16-Ω loads |
| Gain | 2 dB (inverting) |
| Supply Current (Shutdown) | 50 nA |
| Input Impedance | 80 kΩ |
All Texas Instruments TPA6101A2 documents by type
Datasheet 2
Ratings, dimensions and ordering codes, for selection and design work.
