Texas Instruments TSB43AA82A/AI Integrated PHY and Link‑Layer Controller Data Sheet
The TSB43AA82A/AI (iSphynx I) is an integrated PHY and link‑layer controller designed for SBP‑2 and DPP products. This data sheet provides a complete description of its architecture, register set, and functional blocks.
Key information includes package options, mechanical dimensions, electrical characteristics, and usage guidelines. The document also contains a list of illustrations and a detailed table of contents for quick reference.
Texas Instruments TSB43AA82 specifications
| Package Type (PGE) | S‑PQFP‑G144 |
|---|---|
| Package Type (GGW) | S‑PBGA‑N176 |
| Device Function | Integrated 1394 PHY and Link‑Layer Controller |
