Texas Instruments TMS320 Family Development Support Reference Guide
This reference guide describes the TMS320 digital signal processor family and the development support products offered by Texas Instruments. It includes sections on the DSP family generations, typical applications, and the various support resources available to developers.
The document lists software development tools such as the Macro Assembler, C Compiler, and Simulators, as well as hardware development tools like evaluation modules and emulators. It also covers seminars, university programs, third‑party support, and ordering information for TI's development kits.
Texas Instruments TMS320 specifications
| EMU1 Pin to pin spacing | 0.100 in. |
|---|---|
| EMU1 Pin width | 0.025 in. |
| EMU3 pull‑up resistor | 20 kΩ to +5 V |
Source: Texas Instruments TMS320 Family Development Support Reference Guide
