Texas Instruments AM335x Technical Reference Manual
The AM335x Sitara™ processor is a 32‑bit ARM Cortex‑A8 based system‑on‑chip with integrated graphics, crypto, and industrial communication subsystems. It supports a wide range of peripherals including Ethernet, USB, CAN, and multiple memory interfaces.
The document provides detailed device specifications, absolute maximum ratings, clocking information, pin maps for ZCE/ZCZ packages, and a comparison of the AM335x family variants. It is intended for hardware designers and system engineers developing embedded solutions with this processor. This manual is written in Chinese.
Texas Instruments AM335x specifications
| Core processor | ARM Cortex‑A8 up to 1 GHz |
|---|---|
| Instruction RAM | 8 KB with parity (ECC) |
| Addressable memory space | 1 GB |
| Operating temperature range | -40 °C to 125 °C |
| CAN ports | 2 |
| Supported memory interfaces | mDDR, DDR2, DDR3, DDR3L |
All Texas Instruments AM335x documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What core processor does the AM335x use?
It uses an ARM Cortex‑A8 core that can run up to 1 GHz.
How many CAN ports are provided on the AM335x?
The processor provides two CAN ports.
How many UART interfaces are available on the AM335x?
The processor provides six UART interfaces.
What is the maximum CPU frequency of the AM335x processor?
The ARM Cortex‑A8 core can run up to 1 GHz.
