Key facts
- Brand
- STMicroelectronics
- Model
- ST9
- Category
- microcontrollers
- Documents
- 15
- Languages
- EN
- Last added
- 2012-08-09
Start here
Life Fitness T9i Treadmill Operation Manual
This document is the operation manual for the Life Fitness T9i Treadmill. It provides instructions on getting started, including important safety warnings and electrical requirements. The manual details how to use the display console, select various workout programs like Heart Rate Zone Training and Sport Training, and manage user settings.
Read onlineSTMicroelectronics ST9 specifications
| Internal Flash Memory | up to 256 Kbytes |
|---|---|
| Internal RAM | up to 8Kbytes |
| Emulated EEPROM | 1K byte |
| Operating Voltage | 4.5-5.5 V |
| Operating Frequency | 0-24 MHz |
| I/O Pins | Up to 80 |
| A/D Converter Resolution | 10-bit |
Source: ST ST92124xxx-Auto/ST92150xxxxx-Auto/ST92250xxxx-Auto handbook
All STMicroelectronics ST9 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
- ST ST92124xxx-Auto/ST92150xxxxx-Auto/ST92250xxxx-Auto handbook 430 p
- ST92F124xx/ST92F150Cxx/ST92F150JDV1/ST92F250CV2 8/16-bit Flash MCU Datasheet 523 p
- STMicroelectronics ST-9150 Low-Cost Advanced HD Decoding IC Datasheet 11 p
- STMicroelectronics ST-9126 Advanced TV Decoder Datasheet 3 p
- STMicroelectronics ST93C06/ST93C06C 256-bit Serial EEPROM Datasheet 15 p
- ST ST93CS46 ST93CS47 DATA SHEET 16 p
- ST ST93C46A 46C 46T/ST93C47C 47T handbook 13 p
- ST ST90E30 ST90E31 ST90T30 ST90T31 DATA SHEET 22 p
- STMicroelectronics ST92185B 16K/24K/32K ROM HCMOS MCU with On‑Screen‑Display Handbook 178 p
- STMicroelectronics ST92195C/D Datasheet 249 p
- STMicroelectronics ST-9160 Advanced HD Decoder Datasheet 13 p
How to use the product for one specific task, with worked examples.
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the minimum instruction time at 24 MHz?
The minimum instruction time is 83 ns when using a 24 MHz internal clock.
From: ST ST92124xxx-Auto/ST92150xxxxx-Auto/ST92250xxxx-Auto handbook
Does the MCU include a DMA controller?
Yes, it includes a DMA controller to reduce processor overhead.
From: ST ST92124xxx-Auto/ST92150xxxxx-Auto/ST92250xxxx-Auto handbook
What development tools are available?
A free High performance development environment based on Visual Debugger, Assembler, Linker, and C-Compiler is available, along with hardware emulators.
From: ST92F124xx/ST92F150Cxx/ST92F150JDV1/ST92F250CV2 8/16-bit Flash MCU Datasheet
What is the maximum operating frequency for the internal clock?
The device operates at a maximum frequency of 24 MHz using the internal clock.
From: ST92F124xx/ST92F150Cxx/ST92F150JDV1/ST92F250CV2 8/16-bit Flash MCU Datasheet
What networks is the ST-9150 suitable for?
It is suitable for TV markets across all networks including cable, satellite, DTT, xDSL, and IP.
From: STMicroelectronics ST-9150 Low-Cost Advanced HD Decoding IC Datasheet
Does the ST-9150 support DVR capabilities?
Yes, it supports multi-stream transport stream processing and is DVR capable.
From: STMicroelectronics ST-9150 Low-Cost Advanced HD Decoding IC Datasheet
