Key facts
- Brand
- Analog Devices
- Model
- 2136x
- Category
- Processors
- Documents
- 8
- Languages
- EN
- Last added
- 2012-08-03
Start here
ANALOG DEVICES ADSP-2136x SHARC Processor Hardware Reference (includes the ADSP-21362/ADSP-21363/ADSP-21364/ADSP-21365/ADSP-21366 processors) Revision 2.0 June 2009 Manual
This document is the Hardware Reference for the ADSP-2136x family of SHARC processors, specifically covering the ADSP-21362, ADSP-21363, ADSP-21364, ADSP-21365, and ADSP-21366 models. It provides detailed technical information on the processor's architecture, including the core, I/O processor, and various peripherals such as the Digital Applications Interface (DAI), DMA controller, and serial ports.
The manual serves as a comprehensive guide for developers and designers, detailing register definitions, programming models, interrupt handling, and timing specifications. It includes specific sections on configuring DMA transfers, parallel port operations, and serial port configurations, as well as system design considerations like clock generation and pin assignments.
Analog Devices 2136x specifications
| Resolution | 14-bit A/D converter |
|---|---|
| Channels | Four channels |
| Sampling Speed | 2.4 us |
| Supply Voltage | Single 5 V supply |
| Power Consumption | 115 mW (typical) |
Source: Interfacing AD7865 Parallel ADCs to ADSP-2136x SHARC Processors Application Note
All Analog Devices 2136x documents by type
How to use the product for one specific task, with worked examples.
- Analog Devices ADSP-2136x SHARC Processor Asynchronous Sample Rate Converter Programming Guide 8 p
- Analog Devices Code Overlays on Third Generation SHARC Processors EE-230 Application Note 14 p
- Interfacing AD7865 Parallel ADCs to ADSP-2136x SHARC Processors Application Note 7 p
- ANALOG DEVICES Programming S/PDIF on ADSP-2136x ADSP-21371 SHARC Processors (Rev 2 08/2007) Manual 14 p
Instruction set, parameters and examples for configuring or programming the device.
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Disassembly, diagnostics and part numbers, for repair.
Questions answered in these manuals
What is the main application of Sample Rate Converters?
The main application is to change sample rate and clean up audio data from jittery clock sources like S/PDIF receivers.
From: Analog Devices ADSP-2136x SHARC Processor Asynchronous Sample Rate Converter Programming Guide
What type of sample rate converters are implemented in ADSP-21364 processors?
The SRC blocks implemented in ADSP-21364 processors are asynchronous sample rate converters.
From: Analog Devices ADSP-2136x SHARC Processor Asynchronous Sample Rate Converter Programming Guide
What is the main challenge with overlays on third-generation SHARC processors?
The I/O Processor can no longer access 48-bit addresses, so overlays must be copied to equivalent 32-bit locations.
From: Analog Devices Code Overlays on Third Generation SHARC Processors EE-230 Application Note
How are address translations handled for DMA transfers?
The 48-bit run address is translated into an equivalent 32-bit address by multiplying it by 1.5.
From: Analog Devices Code Overlays on Third Generation SHARC Processors EE-230 Application Note
What interfaces are described for connecting the AD7865 to SHARC processors?
The document describes two schemes: the parallel port interface and the parallel data acquisition port (PDAP) interface.
From: Interfacing AD7865 Parallel ADCs to ADSP-2136x SHARC Processors Application Note
How many channels does the AD7865 support?
The device supports four simultaneous sampling channels.
From: Interfacing AD7865 Parallel ADCs to ADSP-2136x SHARC Processors Application Note
