STMPE2401 24-bit Enhanced Port Expander Datasheet

STMPE2401 24-bit Enhanced Port Expander Datasheet

Datasheet 55 pages · 960 KB · EN

The STMPE2401 is a GPIO (General Purpose Input/Output) port expander designed to interface with a Main Digital ASIC via a two-line bidirectional I2C bus. It is commonly used in mobile multimedia platforms to address the limited GPIOs available on digital engines. The device offers high flexibility, allowing each I/O to be configured as an input, output, or specific function such as a keypad scan, PWM output for backlight control, or a rotator decoder interface. It features an ultra-low quiescent current and includes a wake-up feature for each I/O to optimize power consumption.

Read online

STMicroelectronics STMPE2401 specifications

Number of GPIOs24
Operating voltage1.8V
Keypad matrix size8x12
PWM outputs3 (8 bit)
Package typeTFBGA - 36 pins
Pitch0.5mm

Source: STMPE2401 24-bit Enhanced Port Expander Datasheet

All STMicroelectronics STMPE2401 documents by type

Datasheet 1

Ratings, dimensions and ordering codes, for selection and design work.

Application Note 2

How to use the product for one specific task, with worked examples.

Questions answered in these manuals

What is the operating voltage for the STMPE2401?

The device operates at 1.8V.

From: STMPE2401 24-bit Enhanced Port Expander Datasheet

How many GPIOs does the STMPE2401 provide?

The device provides 24 GPIOs.

From: STMPE2401 24-bit Enhanced Port Expander Datasheet

What is the operating voltage of the STMPE2401?

The device functions on a 1.8V supply.

From: ST AN2422 handbook

How many GPIOs does the STMPE2401 provide?

It provides 24 GPIOs.

From: ST AN2422 handbook

What is the maximum size of the keypad matrix supported?

The STMPE2401 supports a maximum 12x8 key matrix.

From: STMicroelectronics STMPE2401 Keypad Controller Application Note AN2423

Can the keypad controller be disabled?

Yes, power consumption can be reduced by setting the 'Enable_KPC' bit in the SYSCON register to zero.

From: STMicroelectronics STMPE2401 Keypad Controller Application Note AN2423
