Philips 107P Manuals

ManualLib has 4 documents for the Philips 107P (Monitors): 3 user manuals, 1 service manual. Every file can be read online or downloaded as a PDF for free.

User Manual 3Service Manual 1

Key facts

Brand
Philips
Model
107P
Category
Monitors
Documents
4
Languages
EN · ZH
Last added
2026-09-28

Start here

Philips 107P Color Display Electronic User's Manual

Philips 107P Color Display Electronic User's Manual

User Manual 131 pages · 1.3 MB · ZH

This document serves as the electronic user's manual for the Philips 107P color display. It covers essential topics including safety precautions, troubleshooting guides, product specifications, and installation instructions. The manual also details the features of the LightFrame technology compatible with this specific model. This manual is written in Chinese.

Read online

Philips 107P specifications

CRT size17 inch (41 cm)
Grille pitch0.25 mm
Horizontal scanning frequency30‑97 kHz
Vertical scanning frequency50‑160 Hz
Video dot rate203 MHz
Input signal level0.7 Vpp
Sync polaritiesPositive and negative

Source: Philips 107P40 Color Monitor User Manual

All Philips 107P documents by type

User Manual 3

Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.

Service Manual 1

Disassembly, diagnostics and part numbers, for repair.

Questions answered in these manuals

Is LightFrame™ 2 compatible with LightFrame™ 3?

No.

From: Philips 107P40 Color Monitor User Manual

Can I upgrade my current Philips monitor to LightFrame™ 3?

No.

From: Philips 107P40 Color Monitor User Manual

Is the LightFrame software compatible with older Philips displays?

No, the software is not compatible with older Philips displays or displays from other manufacturers.

From: Philips 107P Color Display Electronic User's Manual

How many windows can be enhanced simultaneously in LightFrame?

Up to 8 windows can be enhanced at the same time, though overlapping toolbars may reduce this number.

From: Philips 107P Color Display Electronic User's Manual

Is LightFrame 2 compatible with LightFrame 3?

No.

From: PHILIPS 107X display Manual

How many windows can LightFrame 3 enhance at the same time?

LightFrame 3 can enhance up to 8 windows simultaneously.

From: PHILIPS 107X display Manual
