Fairchild RFD16N05L/RFD16N05LSM N-Channel Power MOSFET Datasheet
This document is a datasheet for the Fairchild RFD16N05L and RFD16N05LSM N-Channel Power MOSFETs. These devices are manufactured using the MegaFET process and are designed for use with logic level driving sources in applications such as programmable controllers, switching regulators, and motor relay drivers. They feature a special gate oxide design that provides full rated conductance at gate biases in the 3V to 5V range.
Read onlineAll Fairchild RFD16N05 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What are the package options for the RFD16N05L?
The RFD16N05L is available in TO-251AA and TO-252AA packages.
From: Fairchild RFD16N05L/RFD16N05LSM N-Channel Power MOSFET Datasheet
Can these MOSFETs be driven directly from CMOS circuits?
Yes, they can be driven directly from CMOS, NMOS, and TTL circuits.
From: Fairchild RFD16N05L/RFD16N05LSM N-Channel Power MOSFET Datasheet
What are the primary applications for these MOSFETs?
They were designed for use in switching regulators, switching converters, motor drivers, and relay drivers.
Can these transistors be operated directly from integrated circuits?
Yes, the text states that these transistors can be operated directly from integrated circuits.
