Key facts
- Brand
- Fairchild
- Model
- DM7416
- Category
- Other Electronics
- Documents
- 2
- Languages
- EN
- Last added
- 2012-06-12
Start here
Fairchild Semiconductor DM74164 8-Bit Serial In/Parallel Out Shift Registers Datasheet
This document is a datasheet for the Fairchild Semiconductor DM74164, an 8-bit serial in/parallel out shift register. Key features include gated serial inputs, an asynchronous clear function, and diode-clamped inputs to minimize transmission-line effects. The device operates with a typical clock frequency of 36 MHz and a typical power dissipation of 185 mW.
Read onlineFairchild DM7416 specifications
| Typical clock frequency | 36 MHz |
|---|---|
| Typical power dissipation | 185 mW |
| Package Description | 14-Lead Plastic Dual-In-Line Package (PDIP) |
Source: Fairchild Semiconductor DM74164 8-Bit Serial In/Parallel Out Shift Registers Datasheet
All Fairchild DM7416 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the typical clock frequency of the DM74164?
The typical clock frequency is 36 MHz.
From: Fairchild Semiconductor DM74164 8-Bit Serial In/Parallel Out Shift Registers Datasheet
What is the maximum clock frequency for this device?
The typical clock frequency is rated at 36 MHz.
From: Fairchild Semiconductor DM74164 8-Bit Serial In/Parallel Out Shift Registers Datasheet
What is the function of the DM7416?
The device contains six independent gates each of which performs the logic INVERT function.
From: Fairchild Semiconductor DM7416 Hex Inverting Buffers Datasheet
Do the outputs require external components?
Yes, the open-collector outputs require external pull-up resistors for proper logical operation.
From: Fairchild Semiconductor DM7416 Hex Inverting Buffers Datasheet
